Qualcomm SoC & ARMv8 custom core discussions

Discussion in 'Mobile Devices and SoCs' started by Nebuchadnezzar, Jan 20, 2015.

  1. Grall

    Grall Invisible Member
    Legend

    Joined:
    Apr 14, 2002
    Messages:
    10,801
    Likes Received:
    2,172
    Location:
    La-la land
    Heatpipes, most likely. Like in Sony's Z4/Z5 (Z3 too?)

  2. I.S.T.

    Veteran

    Joined:
    Feb 21, 2004
    Messages:
    3,174
    Likes Received:
    389
    Does anybody know why this SOC is having so many heat issues? Is this a repeat of the infamous 90nm Pentium 4 issue or something?

  3. Nebuchadnezzar

    Legend

    Joined:
    Feb 10, 2002
    Messages:
    974
    Likes Received:
    141
    Location:
    Luxembourg
    Yes. It's a bad physical design implementation.

  4. I.S.T.

    Veteran

    Joined:
    Feb 21, 2004
    Messages:
    3,174
    Likes Received:
    389
    Wonder what happened... Qualcomm isn't exactly a slouch at making chips.

  5. Exophase

    Veteran

    Joined:
    Mar 25, 2010
    Messages:
    2,406
    Likes Received:
    429
    Location:
    Cleveland, OH
    I saw a comment from someone who claimed to be a Qualcomm employee saying that the work was more outsourced than usual. Maybe so they could keep their main teams focused on Kryo.

    It didn't really help that Qualcomm had no prior experience with implementing ARM's flagship cores. And their lower tier implementations (ARM11, A7, A53) may have used ARM hard macros.

  6. Rys

    Rys PowerVR
    Moderator Veteran Alpha

    Joined:
    Oct 9, 2003
    Messages:
    4,156
    Likes Received:
    1,433
    Location:
    Beyond3D HQ
    I think it's that, plus an element of having to get it out of the door quickly regardless of whether it was designed entirely in-house or not.

  7. Nebuchadnezzar

    Legend

    Joined:
    Feb 10, 2002
    Messages:
    974
    Likes Received:
    141
    Location:
    Luxembourg
    That guy was complaining about sourcing/using ARM's architecture instead of in-house, which is totally besides the point and really makes me doubt he has any clue of the issues.
    Qualcomm has been using ARM's cores for a very long time in the low and mid-range, so heat issues with the S615 are not really explained by "inexperience". They don't use ARM macros.

    Rys is right that it was rushed / changed last-minute. The whole industry fucked up all due to the 64bit marketing nonsense and absolutely horrible management overriding engineering decisions. Besides Samsung's 7420 basically every other vendor basically had a wasted year in 2015 and things will only start getting back on track in the coming generation.

    liolio likes this.
  8. Exophase

    Veteran

    Joined:
    Mar 25, 2010
    Messages:
    2,406
    Likes Received:
    429
    Location:
    Cleveland, OH
    That's not what I remember, are you sure we're talking about the same post?

    I'm not convinced experience with the lower end cores directly translates to the higher end ones which are significantly larger and more complex. I could see this still being a blindspot for them.

    Do you have a source that they didn't use hard macros for these parts?

  9. Nebuchadnezzar

    Legend

    Joined:
    Feb 10, 2002
    Messages:
    974
    Likes Received:
    141
    Location:
    Luxembourg
    No but you worded it exactly like one claimed employee was complaining about stuff. Might be two different people.
    I don't think the size of the IP has any impact on the quality of the physical design, maybe a bigger core takes more time but that's about it. Again, I can be wrong here but that's what I understand from researching the matter over the last year or so.
    Yes, pretty certain. Users of ARM's hard macros for seem to be limited to Chinese vendors. Any of the big vendors (QC, Samsung, MediaTek) have their own design teams.

  10. Exophase

    Veteran

    Joined:
    Mar 25, 2010
    Messages:
    2,406
    Likes Received:
    429
    Location:
    Cleveland, OH
    I wonder given Qualcomm's unique position in this space; unlike Samsung, MediaTek or nVidia their ARM cores (until pretty recently) were used only in lower end offerings while their custom cores were used in the medium and high end. They haven't exactly pushed aggressive clock speeds with their Cortex-A5, A7, or even A53 offerings. While there's no doubt that they can do physical implementation I wonder if for these products they don't feel that ARM's implementations are good enough and that their design efforts are better spent focusing on their own cores.

  11. Wishmaster

    Newcomer

    Joined:
    Nov 16, 2008
    Messages:
    238
    Likes Received:
    0
    Location:
    Warsaw, Poland
    After seeing this tweet I suspect that Qualcomm will finally release S820 and reveal all the details this Tuesday. This would coincide with rumored announcement of s820 running xiaomi device on 11th of November.
    What do you think?

  12. wishiknew

    Regular

    Joined:
    May 19, 2004
    Messages:
    332
    Likes Received:
    6
    Was reading the anandtech nexus 5x review. Never knew the 808/810 could throttle so bad as to shutdown the A57s.

  13. mczak

    Veteran

    Joined:
    Oct 24, 2002
    Messages:
    3,015
    Likes Received:
    112
    That's old news though, arstechnica did some article half a year ago showing the same thing: http://arstechnica.com/gadgets/2015/04/in-depth-with-the-snapdragon-810s-heat-problems/
    Except of course the problem is worse with 4 A57 cores... Albeit it seems the power management is a bit different, might be driver differences or something else (like having slightly different allowed surface temperatures).
    That's why I always considered the 810 pointless - the thing has just about the same sustained performance as the 808, the 810 has higher peak performance but the peaks are short enough (compared to the 808) that it probably doesn't really matter (though the 810, being the high-end option, has some other benefits, like a faster ISP).

  14. Nebuchadnezzar

    Legend

    Joined:
    Feb 10, 2002
    Messages:
    974
    Likes Received:
    141
    Location:
    Luxembourg
  15. wishiknew

    Regular

    Joined:
    May 19, 2004
    Messages:
    332
    Likes Received:
    6
    Anandtech's article is up. 2+2 kryos differing in cache/mhz and l3 cache.

    Kinda cool that ultrasonic finger print works thru aluminum.

  16. willardjuice

    willardjuice super willyjuice
    Moderator Veteran Alpha Subscriber

    Joined:
    May 14, 2005
    Messages:
    1,373
    Likes Received:
    242
    Location:
    NY
    Ah interesting no big.little (at least in any meaningful sense). I guess it's a similar concept to the X20 but without the need of a dedicated interconnect. I wonder if there's a different synthesis between the two pairs (I think the X20 was like this too). Regardless, the power curves of the 820 should be intriguing.

    I'm eagerly awaiting your analysis Neb! :smile:

  17. fehu

    Veteran Regular

    Joined:
    Nov 15, 2006
    Messages:
    1,459
    Likes Received:
    391
    Location:
    Somewhere over the ocean
    This is pure scifi 0_0

  18. Nebuchadnezzar

    Legend

    Joined:
    Feb 10, 2002
    Messages:
    974
    Likes Received:
    141
    Location:
    Luxembourg
  19. juicytuna

    Newcomer

    Joined:
    Jul 27, 2005
    Messages:
    71
    Likes Received:
    0
    That memory score is extremely high. Are we looking at a 128 bit interface?

  20. Nebuchadnezzar

    Legend

    Joined:
    Feb 10, 2002
    Messages:
    974
    Likes Received:
    141
    Location:
    Luxembourg
    Likely just a more efficient CPU arch able to take advantage of the memory.
